Détails sur le produit:
|
| Nom: | Aluminium butylique Sapcer pour le double verre | Avantage: | Bord chaud Thchnolgy |
|---|---|---|---|
| Taille: | peut être la demande | Utilisation: | Double verre isolant |
| Surligner: | Butyl Sealing Glass Spacer Bar,Insulating Glass Spacer Bar,Insulating Glass Machine Spacer Bar |
||
Butyl sealing Spacer Bar For insulating glass machine processing
New Generation Compound Aluminium Spacer Space Bar For Hollow Glass
Aluminum compound sealing spacer for IG is a kind of bold innovation based on LIJIANG spacer, perfect combination of aluminum strip and spacer bringing more beautiful spacer and stronger support, together with unique patent design and excellent quality topping the world, making LIJIANG spacer the ideal choice for making insulating glass.
Keywords: warm edge spacer.flexible spacer bar.rubber spacer with aluminum
Use for Manufacturing building doors and windows,Train,Bus,insulating glass ,insulating door, shutter,Refrigeration equipment and so on.
Features:
1.The glass looks more beautiful with the aluminum strip on surface, and the appearance meeting the requirements for aluminum-frame type insulating glass, significantly improving its level.
2.The ageing-resistant performance remarkably enhances. The aluminum strip on surface effectively resists the ultraviolet irradiation, reinforcing the ageing-resistant performance of the spacer to a large extent.
3.Simple operation makes higher production efficiency.Adopting LIJIANG spacer can take the place of complex processing procedure of traditional aluminum-frame type insulating glass.
| Raw material options | |||||
| No. | Material name | Material | producing area | composition | Technical requirements |
| 1 | Inner sealant | Butyl rubber | China | butyl sealant. Calcium powder,polyisobutylene | Q/PHX001-2014 |
| 2 | External sealant | Polymer adhesive | Germany | BASF polyisobutylene,butyl sealant, Calcium | GB/T 19187-2003 |
| 3 | Aluninum strip | 3003 aluminum alloy | China | AL-Mn | GB/T 3190 1996 EN AW 3003/AlMnlCu EN 573 3-1994 |
| 4 | Aluminum foil film | Aluninum foil film | China | Aluainum foil membrane | GB/T 28118-2011 |
| 5 | Molecular seive | 3A nolecular sieve | China | 2/3K20•1/3Na20 •Al203 •2Si02 •9/2H20 | GB/T 10504 2017 |
| 6 | heat-insulating film | PVC | China | PVC | GB3830-83 |
Application:
FAQ:
Q1: Are you a factory or trading company?
A: We are a group company included glass machinery factory glass material factory and trading company, and we are professinal manufacture who produces glass machine and materials in China.
Q2: Where is your factory located?
A: Our factory is located in Jinan City, Shandong Province, China.
Q3. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, the samples are free of charge, but the customers have to pay the courier cost.
Q4: Can you make the product according to my design or original sample?
A: Sure, we have a rich experience of professional and technical staff who will make the most suitable and satisfied designs for you.
Q5. How to ensure product quality?
A: We have 100% inspection during production, you (or your representatives) also can come to inspect the goods before delivery from our factory.
Q6: How do you make our business long-term and good relationship?
A: We will always keep the best quality product and the most competitive price to ensure our clients the best interests. Also we will regard you as our good friend in life and a reliable partner in business cooperation.
Automatic Butyl Machine With CE Hot Melt Butyl Extruder Equipment for insulating processing
Aotomatic Bulyl Extruder Machine with high quolity
Application
PLC control system,touch screen interface
Automatically adjust the amount of glue according to different speeds
Automatically identify the width of aluminum bar,accordingly glue nuzzle can adjust automatically.
Hydraulic systerm uses German components to ensurethat the glue is even and full
Fast preheat,improve work efficiency
with preheating function
With exhaust and inflatable function,improve coating quality and asve time for feeding glue
Quickly coating speed,can up to 47m/min
Squeeze pressure:10-18MPa
Temperature:110-140℃
Aluminumspacerwidth:6A-27A
Speed:5-47m/min
Diameter of butyl cylinder:200mm
Air supply:0.4㎡/min
Air pressure:＞0.6Mpa
Total power:380V,5.7KW,50HZ
Dimension:2800*700*900mm
Weight:650kg
Tech parameters of Automatic hot melt Extruder Machine
| Squeeze pressure | 10-18MPa |
| Temperature | 110~140℃ |
| Glue thickness | 0.3-0.5mm |
| Glue width | 3.5mm |
| Aluminum spacer width | 5.5-26.5mm |
| Speed | 0-47m/min |
| Diameter of butyl cylinder | 200mm |
| Air supply | 0.4m³/min |
| Air pressure | ≥0.6MPa |
| Total power | 380V, 5.7KW,50HZ |
| Dimension | 2800×700×900mm(L×W×H) |
| weight | 750kg |
Equipment details of Automatic Butyl Extruder Insulating Glass machine
Germany Siemens parts
Butyl extruder machine Adopt German brand Siemens PLC, stable performance.
KINCO Touch Screen
Use toubh screen operation ,simple trial,Clear interface, Simple operation, Smart touch screen,Updated programming.
Germany HAVE Valve
High speed butyl extruder machine Adopt Germany’s Harvey valve, more stable performance.
Alarm system
Adopt Automatically alarm system, reminding adding butyl.
Glue cylinder
The rubber cylinder adopt the pull-up structure, which is convenient for changing butyl.
Germany Maximator Cylinder
Super charging system adopts famous pneumatic and hydraulic cylinder, control the pressure of outlet oil strongly.
Adjust the glue putput automatically according to the speed change
The height adjustment of beam is convenient,effective to solve the provlem of white line
Other product of LIJIANG GLASS
Spacer Bending Machine With Aluminum Bars And Warm Bars
Application
The full automatic spacer bending machine is used for making frames ( or other materials) for insulating glass, which replaces the traditional fabrication technology. The Automatic Spacer Bending Machine With Aluminum Bars And Warm Bars can make a variety of convex polygonal aluminum frames by one aluminum strip in one time. The bending machine is available to bend aluminum bars, stainless steel bars, warm bars and thermex and so on. Also on the bending mahcine, also contains printing code , printing label , drilling holes and USB, machine hand for support big frame
Equipment details
Leading Technology
Technical data
| Max.bending size | 2000mm*2000mm (2500mm*2500mm) |
| Min.bending size | 250mm*200mm |
| Aluminum spacer width | 5.5-27mm |
| Dimensional error | ±0.5mm |
| Angle error | ±1º |
| Processing speed | ≤26s |
| Air supply | ≥0.65MPa |
| Total power | AC220/380V 50Hz 2.5KW |
| Dimension | 10500mm*2200mm*2600mm |
Electrical parameters
| NAME | BRAND | NAME | BRAND |
| PLC | GERMAN SIEMENS | Triplet | Taiwan AIRTAC |
| Low voltage electrical apparatus | GERMAN SIEMENS | Cylinder | Taiwan AIRTAC |
| Servo motor | JAPAN FUJI | Solenoid valve | Taiwan AIRTAC |
| Servo driver | JAPAN FUJI | Switch power | Taiwan TEND |
| Relay | JAPAN OMRON | TOUCH SCREEN | Taiwan WEINVIEW |
| Sensor | KOREA AUTONICS | GUIDE | Taiwan TBI |
